Sensors

Name: Gas and TrueVOC Sensor - BRT Systems Pte Ltd
Price: 75.00 USD
Availability: InStock

aaaaaa

Gas and TrueVOC Sensor

Sku: LS-0203-01A

Sku: MS-0203

USD 75.00

Protocols

LDSBus
ModBus

Clear

Specification

Documents

Solutions

Fish Tank Monitor

Home

Office Conference Room

Office

Co-working Space

Library

Vertical Farming

Aquaculture

Car Park

Hydroponics

Data Centre

First Name *

Last Name *

Email address *

Password *

Confirm Password *

Phone (optional)

Country *

I’ve read and accept the terms & conditions *

Specification	Details
Features	Sensor – TVOC Sensor, IAQ Sensor Interface – RS485 LED Indicator (RGB) – System Status Indicator (Please refer to LED section of the datasheet) Mounting – 2 versions available: Flush Mount (Fixed Angle Installation), Swivel Mount (Adjustable Angle Installation)
Power	Input Voltage – 5V DC Bus Power Power Consumption – Typical Power : 183mW, Max. Power: 271mW
TVOC Sensor	TVOC Output Range – 0 to 65000 ppb Accuracy Sensor to Sensor +/- 12% Inital Start Up time – 1 Hour (After each power ON) Initial Stabilisation time – 48 Hours (After first power ON) Warm Up time – 3 Minutes Sampling Rate – 5 seconds
IAQ Sensor	IAQ Output Range 0 – 500 Accuracy Sensor to Sensor +/- 12% Inital Start Up time – 1 Hour (After each power ON) Initial Stabilisation time – 48 Hours (After first power ON) Warm Up time – 3 Minutes Sampling Rate – 5 seconds
Physical Characteristics	Colour – White Housing – Polycarbonate Dimensions – 62mm x H25mm (Flush), 62mm x H60mm (Swivel)
Environmental Limits	Operating Temperature 0^oC to 70^oC Storage Temperature -20^oC to 85^oC Ambient Relative Humidity 5 to 95% (non-condensing)
Package Contents	Device – 1X LDSBus Gas and TrueVOC Sensor Flush (or) 1X LDSBus Gas and TrueVOC Sensor Swivel Wire Assembly – 1X 5m RJ11-JST Cable Self-Tapping Screws – 2X M3*16mm (Thread)

Specification	Details
Features	Sensor – TVOC Sensor, IAQ Sensor Interface – RS485 Modbus RTU LED Indicator (RGB) – System Status Indicator (Please refer to LED section of the datasheet) Mounting – 2 versions available: Flush Mount (Fixed Angle Installation), Swivel Mount (Adjustable Angle Installation)
Power	Input Voltage – 5V DC Bus Power Power Consumption – Typical Power : 183mW, Max. Power: 271mW
TVOC Sensor	TVOC Output Range – 0 to 65000 ppb Accuracy Sensor to Sensor +/- 12% Inital Start Up time – 1 Hour (After each power ON) Initial Stabilisation time – 48 Hours (After first power ON) Warm Up time – 3 Minutes Sampling Rate – 5 seconds
IAQ Sensor	IAQ Output Range 0 – 500 Accuracy Sensor to Sensor +/- 12% Inital Start Up time – 1 Hour (After each power ON) Initial Stabilisation time – 48 Hours (After first power ON) Warm Up time – 3 Minutes Sampling Rate – 5 seconds
Physical Characteristics	Colour – White Housing – Polycarbonate Dimensions – 62mm x H25mm (Flush), 62mm x H60mm (Swivel)
Environmental Limits	Operating Temperature 0^oC to 70^oC Storage Temperature -20^oC to 85^oC Ambient Relative Humidity 5 to 95% (non-condensing)
Package Contents	Device – 1X Modbus Gas and TrueVOC Sensor Wire Assembly – 1X Modbus RS485-JST Cable (30cm) Self-Tapping Screws – 2X M3*16mm (Thread)
